CCi2

CCI2

CCi2

CCI2

Warm and detailed SQ , high bias circuitry with unique heat management, tuned by Gordon Taylor, advanced HLC input, versatile active crossovers, cooling fan

Specifications

Channels

Two

Amplifier class

AB

Power RMS (2 Ohm)

2x170W

Power RMS (4 Ohm)

2x110W

Bridged Power RMS (4 Ohm)

1x340W

THD

20 kHz <0,25%

S/N ratio

> 110 dB

Freq.range

10 – 50 000 Hz

Input Sensitivity

1-4V

High Pass Filter

50 – 500 Hz

Low Pass Filter

50 – 500 Hz

Dimension (W x D x H)

129 x 260 x 51mm

Weight

1,87 kg

Description

“Probably one of the best SQ amps in the world in terms of price / performance”

Two channel audiophile amplifier for high demands tuned by Gordon Taylor. The appraised DLS sound is secured by linear regulators supplying the preamp and a high bias drive circuitry. Combined with top quality output devices it simply makes DLS amplifiers sonically superior to competitors. Glimmering details with warm midrange and a class leading S/N ratio of over 110 dBA — the amp is dead quiet!

When used for system integration the CCi2 includes DLS High level converter with Auto start for serious upgrading of OEM radios and wide range input level handling. Another useful function of the Hi Level input is that a low-level output to additional amplifiers can be sourced from the RCA input connectors.



Damping factor >150

Input impedance 6 kohm

Input impedance, high level 45 ohm

High level input with auto start Yes

Power consumption (idle) 0,5 A

Power consumption (max) 43 A

Integrated fan

Specifications

Channels

Two

Amplifier class

AB

Power RMS (2 Ohm)

2x170W

Power RMS (4 Ohm)

2x110W

Bridged Power RMS (4 Ohm)

1x340W

THD

20 kHz <0,25%

S/N ratio

> 110 dB

Freq.range

10 – 50 000 Hz

Input Sensitivity

1-4V

High Pass Filter

50 – 500 Hz

Low Pass Filter

50 – 500 Hz

Dimension (W x D x H)

129 x 260 x 51mm

Weight

1,87 kg

Download manual

Download
