Signature S1

DLS new Signature Series.

Designed and sound tuned by Gordon Taylor in cooperation with DLS Sweden, the Signature series amplifiers all share the unique intelligent cooling of the small footprint casing. All made with the highest build quality and the warm, rich, noise free sound that made DLS amplifiers famous all over the Car Audio World.

The S1 is conservatively specified to deliver 1×1200 W RMS in 2 Ohm class D with a signal to noise ratio of more than 110 dB, so there is a lot of power to spare even in demanding applications.

Number of channels – 1
Amplifier class – D
Mono bridge mode 4 ohm – 2 x 220 Watt
Output power in 2 ohm – 1 x 1200 Watt
Output power in 4 ohm – 4 x 85 Watt
Damping factor >300
THD at 5W, 1 kHz. <0,02%
S/N ratio, A-weighted >110 dB
Frequency range 10 Hz – 60 kHz
Input sensitivity 1 – 4 Volt
Input impedance 6 kohm
Input impedance, high level 45 ohm
Filter high pass 50 – 500Hz
Filter low pass 50 – 500Hz
Power consumption (idle) 0,7 A
Power consumption (max) 64 A
High level input with auto start Yes
Integrated fan
Dimension (W x D x H) 129 x 370 x 54 mm (5,1″ x 12,6″ x 2,1″)
Weight 1,87 kg
