Signature S4 24V

S424V

Signature S4 24V

S424V

A truly great amplifier does not make any sound at all. The Signature series has unrivalled low distortion and an extremely high signal-to-noise ratio, now for 24V!

Specifications

Channels

Four

Amplifier class

AB

Power RMS (2 Ohm)

4x160W

Power RMS (4 Ohm)

4x105W

Bridged Power RMS (4 Ohm)

2x320W

Freq.range

10 – 60 000 Hz

Low Pass Filter

50 – 500 Hz

Dimension (W x D x H)

129 x 320 x 54 mm

Weight

2,4 kg

Description

The Next Evolution of DLS

2019 marked the 40th year anniversary of DLS. Four decades of giving enthusiasts exactly what they wanted, but we knew we could do even better. Together with Gordon Taylor we set out on a new journey to create perfection.

Silence is Golden

A truly great amplifier does not make any sound at all. The Signature series has unrivalled low distortion and an extremely high signalto- noise ratio, letting you hear only music and experience new details in your favourite songs with a warm clarity and a firm mid bass with impressive authority.

Optimised for Perfection

No detail has been left untweaked, from the custom cooling system tothe power supply. We have even trimmed each channel individually and synchronised every component with each other to perform in perfect harmony. When used together with a Digital Sound Processor there is an option to bypass all preamp circuitry, letting the DSP get complete control of all sound tuning parameters. This allows a clean and unaltered signal to reach the amplifying stage in full without sonic degradation. Enjoy music in full, unaltered and perfect, with the Signature series.

Damping factor >300

THD at 3W, 20Hz-20kHz <0,065%

THD at 85W, 1kHz <0,065%

S/N ratio, A-weighted 110 dB

Input sensitivity 1 – 4 Volt

Input impedance, low level 5 kohm

Input impedance, high level 3.3 ohm

Filter high pass 50-500 Hz

Power consumption (idle) 0,4 A

Power consumption (max) 32 A

Internal cooling fan

Specifications

Channels

Four

Amplifier class

AB

Power RMS (2 Ohm)

4x160W

Power RMS (4 Ohm)

4x105W

Bridged Power RMS (4 Ohm)

2x320W

Freq.range

10 – 60 000 Hz

Low Pass Filter

50 – 500 Hz

Dimension (W x D x H)

129 x 320 x 54 mm

Weight

2,4 kg

Download manual

Download
