M226

One of the most popular upgrades from original 16cm (6,5″) speakers.

The custom slim basket on M226 makes it possible to use nearly everywhere a good 2-way coaxial is wanted. The fibreglass woofer cone and foam surround are acoustically mixed for best performance. External 3-wire in-line crossover & grilles are included.

Tweeter 16 mm (0,63″) mylar tweeter
Woofer size 16,5 cm (6,5″)
Power handling capacity 50 W RMS / 75 W max / 150 W peak power
Impedance 4 ohm
Frequency range 70 – 18.000 Hz
Sensitivity 85 dB (1W/1m)
Crossover Cable filter with 6/12 dB slope (HP/LP)
Outer diameter of woofer 165 mm (6,5″)
Cone material Polypropylene, foam surround
Magnet size 80 mm (3,15″)
Mounting depth 45 mm ( 1,77″)
Mounting hole 145 mm (5,7″)
