Performance RCS10.D2

RCS10D2

Performance RCS10.D2

RCS10D2

Impressive 10″ subwoofer engineered with great performance in a super slim construction

Specifications

Size	10"/250mm
Impedance	2+2 Ohm
Power RMS	600W
Power MAX	1200W
Sensitivity	85 dB
Voice coil size	2.5"/63.5mm
Voice coil material	4-layer copper/TIL former
Cone material	Sandwich composite PP dust cap
Magnet	65 Oz Ferrite
Freq.range	25 – 500 Hz
Weight	6 kg

Description

Impressive subwoofer engineered with great performance in a super slim construction. The Reference series is developed for real music lovers. Filled with innovative solutions, delivering a warm and embracing sound.

•Truly compact with less than 4” (10cm) mounting depth. Suitable in 10-15 liter enclosures.

•Dual 2 Ohm voice coil for the purists who want to adapt the bass after their own preference.

Parameters:

Fs: 33 Hz

Re: 3.8 (1.9+1.9) Ohm

Qms: 6.37

Qes: 0.51

Qts: 0.47

Cms: 0.15 mm/N

Mms: 149.9g

Bl: 15.4

Vas: 26.2L

SD: 346.4 cm²

Xmax: ±11 mm

Vd: 1.7 L

Specifications

Size	10"/250mm
Impedance	2+2 Ohm
Power RMS	600W
Power MAX	1200W
Sensitivity	85 dB
Voice coil size	2.5"/63.5mm
Voice coil material	4-layer copper/TIL former
Cone material	Sandwich composite PP dust cap
Magnet	65 Oz Ferrite
Freq.range	25 – 500 Hz
Weight	6 kg

Download manual

Download Specification and Datasheet
